SSAC SQ4413M Timing Relay 120VAC 0.5A, BNIB / NOS
sku105032 — low stock
Request a Quote
By SSAC
<p> The SQ Series is available with either three (SQ3) or four (SQ4) outputs and an adjustable or fixed time delay. The time delay period is the same for each output. This makes the SQ ideal for applications like dust collection, automatic lubrication, air drying, lighting displays, merchandisi…
Description
<p> The SQ Series is available with either three (SQ3) or four (SQ4) outputs and an adjustable or fixed time delay. The time delay period is the same for each output. This makes the SQ ideal for applications like dust collection, automatic lubrication, air drying, lighting displays, merchandising displays, duty cycling, and energy management.
Operation (Sequencing): Upon application of input voltage, Load 1 energizes for the selected ON time delay. At the end of this ON time delay, Load 1 de‑energizes and Load 2 immediately energizes starting another ON time delay. At the end of this ON time delay, Load 2 de‑energizes and Load 3 immediately energizes. At the end of the ON time delay for Load 3 (Load 4 for 4 output devices), Load 1 reenergizes and the cycle repeats. The sequential operation continues as long as input voltage is applied. Reset: Removing and re‑applying input voltage resets the sequence to the Load 1 ON time delay.
 </p><p>Mode Of Operation : Sequencing</p><p>Timing Range: 3 minutes</p><p>Mounting Type: Surface</p><p>Contact Rating: 1 Amps</p><p>Termination: .250in. Flat Bed</p><p>Adjustment Type: Fixed</p><p>Max Time: 3 Min</p><p>Time Tolerance: 10 percent</p><p>Coil Voltage 120VAc</p><p>Approvals CE; ULr</p><p>Comments: Four Outputs</p>
Operation (Sequencing): Upon application of input voltage, Load 1 energizes for the selected ON time delay. At the end of this ON time delay, Load 1 de‑energizes and Load 2 immediately energizes starting another ON time delay. At the end of this ON time delay, Load 2 de‑energizes and Load 3 immediately energizes. At the end of the ON time delay for Load 3 (Load 4 for 4 output devices), Load 1 reenergizes and the cycle repeats. The sequential operation continues as long as input voltage is applied. Reset: Removing and re‑applying input voltage resets the sequence to the Load 1 ON time delay.
 </p><p>Mode Of Operation : Sequencing</p><p>Timing Range: 3 minutes</p><p>Mounting Type: Surface</p><p>Contact Rating: 1 Amps</p><p>Termination: .250in. Flat Bed</p><p>Adjustment Type: Fixed</p><p>Max Time: 3 Min</p><p>Time Tolerance: 10 percent</p><p>Coil Voltage 120VAc</p><p>Approvals CE; ULr</p><p>Comments: Four Outputs</p>
