Mark 10 MG50 Digital Force Gauges, 50 x 0.05 lb, 25 x 0.02 kgF, 250 x 0.2 N, 110V,
sku1059710+ in stock
10% Store Wide!Save $12.50
$112.50CAD$125.00
By Mark-10
<p>The Series MG Digital Force Gauge is an economical solution for push and pull testing of up to 500 lb. A rugged reversible aluminum housing allows for hand-held use or test stand mounting. Three pushbuttons allow the user to easily select units of measurement, reset zero, and recall tensile and c…
Description
<p>The Series MG Digital Force Gauge is an economical solution for push and pull testing of up to 500 lb. A rugged reversible aluminum housing allows for hand-held use or test stand mounting. Three pushbuttons allow the user to easily select units of measurement, reset zero, and recall tensile and compressive peak loads. Use the MG with a test stand and gripping fixtures to create a complete testing solution.
 </p><ul><li>    Compatible with all Mark-10 test stands and grips.</li><li>    Small size</li><li>    Reversible aluminum housing for hand use or stand mounting</li><li>    Peak memory for tensile and compressive loads</li><li>    Programmable automatic shutoff</li><li>    Programmable default configuration</li><li>    Push-button calibration</li><li>    IPM - Intelligent Power Management system</li><li>    Selectable units of measurement</li><li>    Battery or AC operation</li><li>    Same housing size for all capacities</li><li>    Accuracy: ± 0.5% of full scale ±1 digit</li><li>    Environmental requirements: 40°F - 100°F [5°C - 45°C], <96% humidity (non-condensating)</li><li>    Safe overload: 150% of capacity</li><li>    Weight: 0.7 lbs (0.3 kg)
 </li></ul>
 </p><ul><li>    Compatible with all Mark-10 test stands and grips.</li><li>    Small size</li><li>    Reversible aluminum housing for hand use or stand mounting</li><li>    Peak memory for tensile and compressive loads</li><li>    Programmable automatic shutoff</li><li>    Programmable default configuration</li><li>    Push-button calibration</li><li>    IPM - Intelligent Power Management system</li><li>    Selectable units of measurement</li><li>    Battery or AC operation</li><li>    Same housing size for all capacities</li><li>    Accuracy: ± 0.5% of full scale ±1 digit</li><li>    Environmental requirements: 40°F - 100°F [5°C - 45°C], <96% humidity (non-condensating)</li><li>    Safe overload: 150% of capacity</li><li>    Weight: 0.7 lbs (0.3 kg)
 </li></ul>
