Marconi 2305 Modulation Meter with GPIB & 46883-527G Distortion & Weighting Filter Option
sku51262 — low stock
$2,375.00CAD
By Marconi
The 2305 Modulation Meter is an automatic tuning instrument suitable for a wide range of measurements on signal sources. Conventional measurements such as F.M. or P.M. deviation and A.M. depth are made with excellent resolution and high accuracy over a carrier frequency range from 500 kHz to 2 GHz. …
Description
The 2305 Modulation Meter is an automatic tuning instrument suitable for a wide range of measurements on signal sources. Conventional measurements such as F.M. or P.M. deviation and A.M. depth are made with excellent resolution and high accuracy over a carrier frequency range from 500 kHz to 2 GHz.
- SPECIFICATIONS:
- Carrier Frequency Range: 500 kHz to 2 GHz
- Basic Accuracy: ±0.5%
- Automatic Tuning: Tunes automatically to strongest signal in range
- Frequency Indication: 8 digit LCD
- Manual Tuning: Front keyboard or GPIB
- Sensitivity: -25 dBm to -15 dBm 0.5 Mhz to 2 GHz
- Max Deviation: 500 kHz peak deviation at modulation rates of 30 Hz to 275 kHz at carrier frequencies above 5.5 MHz
Additional specifications available upon request.
