Home›Products›Meters›Multimeters & Voltmeters›Keithley 595 Quasistatic CV Meter, 10fF-20nF, DC Current 1 fA-200uA, Output -20-20V, Max. Input 30V peak
Keithley 595 Quasistatic CV Meter, 10fF-20nF, DC Current 1 fA-200uA, Output -20-20V, Max. Input 30V peak
sku99221 — low stock
$3,150.00CAD
By Keithley
<ul text-align:="" style=""><p>Keithley 595 Quasistatic CV Meter, 10fF-20nF, DC Current 1 fA-200uA, Output -20-20V, Max. Input 30V peak</p></ul><ul text-align:="" style="list-style-position:"><p>Quasistatic C-V measurements are commonly applied to characterize MIS devices. They are used in the meas…
Description
<ul text-align:="" style=""><p>Keithley 595 Quasistatic CV Meter, 10fF-20nF, DC Current 1 fA-200uA, Output -20-20V, Max. Input 30V peak</p></ul><ul text-align:="" style="list-style-position:"><p>Quasistatic C-V measurements are commonly applied to characterize MIS devices. They are used in the measurement of interface trap density and doping profiles corrected for the presence fo interface traps. Quasistatic C-V is also used to measure mobile ion density by the triangular voltage-sweep method.</p><p>Features:</p><li>4 1/2 Digit LCD Display</li><li>DC Current 1 fA-200uA</li><li>Output -20-20V,</li><li>Analog Output: + 1V=  10,000 counts on x1 gain; 1V=1000 counts on x10 gain</li><li>Max Input 30V peak</li><li>Power 105-125VAC or 210-250VAC, 50-60 Hz, 15 VA Max.</li></ul><p> </p><p> </p><p> </p><p> </p>
