Hammond PT1000MEMX Transformer 1PH, 50/60Hz, 1kVA 600V pri 120/240 sec BNIB / NOS

Description

<p>Hammond PT1000MEMX Transformer 1PH, 50/60Hz, 1kVA 600V pri 120/240 sec BNIB / NOS
</p><p>
Brand: &#160; &#160; &#160; &#160; &#160; &#160; &#160;&#160; &#160;&#160;&#160; Hammond Power Solutions
Mfg part number &#160;&#160;&#160; PT1000MEMX</p><p>
Specifications:</p><p>Electrical Specifications:
</p><p>1PH, 50/60Hz, 1kVA, 1K Rating
Primary configuration: &#160; &#160; &#160; &#160;&#160; 600Volts
Secondary configuration: &#160;&#160;&#160; Two Winding 120/240 Volts
Reverse connectable: &#160; &#160;&#160; &#160;&#160;&#160; Yes
Winding material: &#160; &#160; &#160; &#160; &#160; &#160;&#160; &#160;&#160;&#160; Copper
Electrostatically shielded: &#160;&#160;&#160; No
Connection type: &#160; &#160; &#160; &#160; &#160; &#160;&#160; &#160;&#160;&#160; Screw Terminals</p><p>
Mechanical Specifications:
Temperature rise (deg C): &#160;&#160;&#160; 80
Insulation system (deg C): &#160;&#160;&#160; 130
Construction style: &#160; &#160; &#160; &#160; &#160;&#160; &#160;&#160;&#160; Open - Cast or Encapsulated Core &amp; Coil
Mounting type: &#160;&#160;&#160; &#160; &#160; &#160; &#160; &#160; &#160; &#160; &#160;&#160;&#160; Base/panel
Cooling: &#160;&#160;&#160; Air/Dry</p><p>
Other Information:
UL listed
Agency approvals &#160;&#160;&#160; CE Marked, RoHS Compliant</p><p>
Weight &amp; Dimensions:
Weight &#160;&#160;&#160; 23.60 lbs. (10.70 kg)
LxWxH &#160;&#160;&#160; 6.81 x 5.25 x 4.94 in.
(17.30 x 13.34 x 12.55 cm)</p>
