Home›Products›Vacuum Equipment & Systems›Vacuum Pumps›Edwards nRV14i Two Stage Oil Sealed Rotary Vane Pump 100-240 Vac
Edwards nRV14i Two Stage Oil Sealed Rotary Vane Pump 100-240 Vac
SKU133001 — low stock
$4,350.00CAD
By Edwards
MANUFACTURERS INFORMATION: Pumping speed m3h-1/ft3h-1 14.2/8.4 Ultimate pressure no gas ballast mbar/Torr 2 x 10-3/1.5 x 10-3 Ultimate with gas ballast 1 mbar/Torr 3 x 10-2/2.3 x 10-2 Ultimate with gas ballast 2 mbar/Torr 1.2 x 10-1/ …
Description
MANUFACTURERS INFORMATION:
Pumping speed m3h-1/ft3h-1 14.2/8.4
Ultimate pressure no gas ballast mbar/Torr 2 x 10-3/1.5 x 10-3
Ultimate with gas ballast 1 mbar/Torr 3 x 10-2/2.3 x 10-2
Ultimate with gas ballast 2 mbar/Torr 1.2 x 10-1/
9.1 x 10-2
Water vapour tolerance (gas ballast 2) ghr-1 290
Inlet port NW25
Outlet port NW25
Power supply 100 -240 V AC +/- 10% 50/60 Hz
Power connection IEC 60320 C19
On/off control Manual, remote parallel and serial comms
Serial communications RS232 and RS485
Noise (Pressure) dB(A) <55
Ambient temperature range °C 12 to 40
Cooling Air Cooled
Weight without oil kg/lb 31.5 / 69.3
Oil type Ultragrade 19
Oil capacity min-max litre 0.65-1.0
