Home›Products›Industrial Equipment & Automation›Gauges, Readouts & Industrial Counters›Brooks MT 3810 / MT3810 / 3810A13A1QAAAA1 Armored Rotameter / Flow Indicator with Dial Indicator rm BRAND NEW / NOS
Brooks MT 3810 / MT3810 / 3810A13A1QAAAA1 Armored Rotameter / Flow Indicator with Dial Indicator rm BRAND NEW / NOS
sku69923 — low stock
10% Store Wide!Save $57.50
$517.50CAD$575.00
By Brooks
<h3 class="icon-head head-products">Brooks MT3810 / 3810A13A1QAAAA1 Armored Rotameter BRAND NEW / NOS rm</h3><p>Brooks<sup>®</sup> MT3810 armored rotameters are ideal for high pressure, high temperature and other demanding applications where safety is a concern.</p><p>NOTE:  The spec sheet sa…
Description
<h3 class="icon-head head-products">Brooks MT3810 / 3810A13A1QAAAA1 Armored Rotameter BRAND NEW / NOS rm</h3><p>Brooks<sup>®</sup> MT3810 armored rotameters are ideal for high pressure, high temperature and other demanding applications where safety is a concern.</p><p>NOTE:  The spec sheet says A should be Gas GPM (Maximum Flow Based on Water/Air: <span style="color: rgb(255, 0, 0);"> </span><span style="color: rgb(255, 0, 0);">5.2 GPM, 1200 L/H, 19 SCFM, 30 NM3/H) </span>, but the face of the meter does not show this, so we are NOT SURE if the specs are correct or not.  The PART number is definitely accurate, as are the photos.</p><p>3810A 1 3 A 1 Q A A A A 1</p><p><span style="color: rgb(255, 0, 0);">3810A:</span> Basic Model Type: <span style="color: rgb(255, 0, 0);">Thru-Flow Meter, Threaded Connections</span>
<span style="color: rgb(255, 0, 0);">         1:</span> Materials: <span style="color: rgb(255, 0, 0);">316/316L SS</span>
<span style="color: rgb(255, 0, 0);">         3: </span>Meter and Connectivity Size: <span style="color: rgb(255, 0, 0);">Meter Size 10, Connection 1" NPT (f), Meter Lay Length 300mm NPT (f)</span>
<span style="color: rgb(255, 0, 0);">         A: </span>SEE ABOVE
<span style="color: rgb(255, 0, 0);">         1: </span>Connection Type: <span style="color: rgb(255, 0, 0);">1" NPT (f) with Viton O'Ring</span>
<span style="color: rgb(255, 0, 0);">         Q: </span>Meter Accuracy  / Scale Inscription / Fluid:  <span style="color: rgb(255, 0, 0);">5% Full Scale,  Scale Inscription = % Scale,  Fluid = Gas</span>
<span style="color: rgb(255, 0, 0);">         A: <span style="color: rgb(0, 0, 0);">Housing:  </span>Standard, Material - Aluminum, Finish - Polyurethane, Indicator
              Function - Indicator Only</span>
<span style="color: rgb(255, 0, 0);">         A: </span>Relay/Power Supply Options:  <span style="color: rgb(255, 0, 0);">None</span>
<span style="color: rgb(255, 0, 0);">         A: </span>Certifications:  <span style="color: rgb(255, 0, 0);">None</span>
<span style="color: rgb(255, 0, 0);">         A: </span>Accessories:  <span style="color: rgb(255, 0, 0);">None</span>
<span style="color: rgb(255, 0, 0);">         1: </span>Software Revision Level for uP Transmitter:  <span style="color: rgb(255, 0, 0);">No Applicable, uP TrAnsmitter no part of meter</span></p><p> </p><p> </p><p> </p><p> </p><p> </p><p> </p>
<span style="color: rgb(255, 0, 0);">         1:</span> Materials: <span style="color: rgb(255, 0, 0);">316/316L SS</span>
<span style="color: rgb(255, 0, 0);">         3: </span>Meter and Connectivity Size: <span style="color: rgb(255, 0, 0);">Meter Size 10, Connection 1" NPT (f), Meter Lay Length 300mm NPT (f)</span>
<span style="color: rgb(255, 0, 0);">         A: </span>SEE ABOVE
<span style="color: rgb(255, 0, 0);">         1: </span>Connection Type: <span style="color: rgb(255, 0, 0);">1" NPT (f) with Viton O'Ring</span>
<span style="color: rgb(255, 0, 0);">         Q: </span>Meter Accuracy  / Scale Inscription / Fluid:  <span style="color: rgb(255, 0, 0);">5% Full Scale,  Scale Inscription = % Scale,  Fluid = Gas</span>
<span style="color: rgb(255, 0, 0);">         A: <span style="color: rgb(0, 0, 0);">Housing:  </span>Standard, Material - Aluminum, Finish - Polyurethane, Indicator
              Function - Indicator Only</span>
<span style="color: rgb(255, 0, 0);">         A: </span>Relay/Power Supply Options:  <span style="color: rgb(255, 0, 0);">None</span>
<span style="color: rgb(255, 0, 0);">         A: </span>Certifications:  <span style="color: rgb(255, 0, 0);">None</span>
<span style="color: rgb(255, 0, 0);">         A: </span>Accessories:  <span style="color: rgb(255, 0, 0);">None</span>
<span style="color: rgb(255, 0, 0);">         1: </span>Software Revision Level for uP Transmitter:  <span style="color: rgb(255, 0, 0);">No Applicable, uP TrAnsmitter no part of meter</span></p><p> </p><p> </p><p> </p><p> </p><p> </p><p> </p>
